AHD Camera System - 2x 1080P camera with 20m IR and Hybrid DVR

AHD camera system includes 2 camera 1080P with 20m IR and hybrid DVR AHD 1080P/960H/720P. CCTV surveillance system is easy to use and includes 2 AHD 1080P cameras and hybrid DVR recorder AHD (possible to connect 2 more cameras) 1080P/960H/720P, which will record in Full 1080p in real time. To use the system you need to buy HDD (hard disk 1 - 4TB) adapted for a 24 hour operation, which can be bought as an optional accessory.

4-channel DVR IQCCTV hybrid recorder (HD1080P, HD720P, 960H) - offers the most modern digital recording via a standard cables. The recorder can record camera image either from 1080P/720P/960H cameras, or from conventional analog cameras and automatically captures it in the same format as the camera. The recorder also has 4 audio inputs and 1 output if you wish to add a sound.

DVR unit can record all 4 cameras simultaneously at 15fps in Full HD 1080P or at 25fps in 720P or 960H resolution. DVR provides Full HD output to a monitor using VGA or HDMI. Once the set is connected to a network (internet) you can easily view and control it from anywhere in the world using a smartphone (Android), tablets, PC and Mac (iOS) computers.

Application "XIQ Mobile CMS" for tablets and smartphones you can download for free in the app store and using the "Snap Shots" function you can set up e-mail alerts that are really useful. You will certainly appreciate alerts when there is some disruption of area monitored by security cameras.

Another new feature is the option to automatically send video/photo files via the app Dropbox online service for sharing and backing up of files, either at the motion detection, or at the set intervals. The service provides additional protection for recorded files.

You do not need to have a fixed IP address or to log in to the DDNS service. For those who do not want to use direct IP connection is also available HD CCTV feature that is added to the new series of DVR. It gives you the ability to remotely connect via a dynamic IP address. The application also allows multi-camera viewing and the ability to play recorded images from DVR.

Security AHD camera Full HD1080p + IR LED 20 m + antivandal camera with a diameter of 3,6 mm lens and IR night vision with distance of 20 m. The camera is equipped with a wide angle lens that scans at angle of 78°. The camera disposes with Full HD 1080p.

The camera also has night vision IR up to distance of 20 meters (it is activated automatically upon detection of lower light) that allows continuous monitoring even in complete darkness. After dark or in low light conditions, the camera automatically switches from the color scanning to black-white mode. Automatic IR filter produces quality color images during the day and clear images at night in combination with IR LED illumination.

It is ideal for indoor and outdoor use (IP65) and has a compact design. Can be installed on the wall using a console.

AHD systems 1080p

The latest technology of camera system that comes as the successor of analog systems, but in high-resolution 1280x720px and 1920x1080px. That´s why it has a unique technology that enables video transmission through coaxial cable (up to 500m).

 Simple infrastructure
 Analog connection and conduction
 Signal transmission through cable up to 500m
 More technologies of signal transmission
Digital recording on hard disks
Possibility of remote control (LAN)

Technical specifications DVR:

• ModelIQR1080D4
• Video compressionH.264
• Video systemPAL / NTSC
• Video input/output4 Ch. inputs, 1 VGA, 1 HDMI
• Audio input/output4 Ch. input, 1 Ch. output (RCA)
• Display resolutionPAL: 960x576 / 1280x720 / 1920x1080 @ 25fps
• Display functionSingle, Quad, SEQ
• Recording resolutionPAL: 960x576 (960H), 1280x720 (720p), 1920x1080 (1080p)
• Recording speedPAL: 960H Mode / 720P mode: 25fps 1080p 15fps
• Recording modeContinuous / Manual / Motion Detection
• Playback channels1/4 Ch.
• Frame ratePAL: 960H Mode / 720P mode: 25fps 1080p 15fps
• DVD-RWNo
• Sensor and Alarm I/ONo
• IR Extender PortNo
• NetworkLAN, DHCP, Dynamic IP and DDNS
• HDD Interface1 SATA HDD up to 6 TB
• OperationLive view, recording, playback, backup and network
• USB2 x USB (for mouse and backup/upgrade)
• PTZ controlYes
• Mobile SurveillanceXIQ CMS - Android and iOS
• CMS SoftwareYes
• Web browserInternet Explorer, Safari, Chrome, Firefox
• VGA800x600, 1024x768, 1280x1024, 1440x900, 1920x1080
• HDMI 1080p
• Power supply12V DC
• FanNo
• On/Off SwitchNo
• Remote controlYes
• Dimensions (WxHxD)300x53x227

The camera parameters:

• ModelIQC1080V
• TypeSecurity Camera
• Resolution1080P/HD960H
• Sensor type 1 / 2,7 "CMOS Sensor Mega Pixel
• DSP TypeIQ 1080P DSP
• Minimum illumination0.1 Lux (0 Lux IR On)
• DSP FunctionAutomatic Backlight Compensation
• Auto white balance
• Auto electronic shutter
• Night Vision20m IR Night Vision
• Lens typeFixed
• Lens size3,6 mm
• Angle78 °
• Operating voltage12V DC
• Video outputBNC socket
• Audio outputNo
• Weather-resistantYes (IP65)
• Resistant to damage (Antivandal)yes
• The mounting methodwall or ceiling
• Dimensions (WHD in mm)93x78x93
• Weight (kg)0,40

Contents:

• 2x Camera - IQC1080V
• 2x 20 m cable for video/audio/power
• 2x Installation material (screws, dowels)
• 2x power adapter of camera 12V 1250 mA
• 1x DVR - IQR1080D4
• 1x Power Adapter DVR
• 1x USB mouse
• 1x Remote Control
• 1x Installation CD
• 1x Manual
