8 Channel HD DVR with 1 TB capacity for 960H camera

SKU: 41-022 I have a question
Manufacturer X Vision
Products availability pre-order
Delivery time 1 - 3 weeks.
Yes! We Ship To US
Price excl. VAT U$ 622.41
Price incl. VAT U$ 746.90
- +

Product description 8 Channel HD DVR with 1 TB capacity for 960H camera

Professional 8 Channel DVR with HD resolution 960H with 1 TB capacity for the record. This 8 - channel DVR is the latest professional DVR from Xvision with advanced features, which offers high resolution 960H and record in real time.

It is designed to offer something more than just the standard 960H DVR, supports PTZ cameras via RS - 485, as well as flexible recording modes, including activation of alarms and motion detection.
For easy operation and setup the DVR is equipped with On Screen Display (GUI) and can be controlled via the front panel, remote control or mouse (both are supplied as standard). Besides those, it offers VGA, BNC and HDMI output up to 1080p.


● Recording Speed: WCIF/D1/HD 960H: 200fps in real time (25fps on camera)
● 8 audio inputs
● Remote access via smartphone, tablet, PC and Mac
● Instant Video Push Notification: iPhone / Android smartphones
● E-mail alerts
● Control via: Front panel, mouse, IR remote control or
● 3G/4G USB Dongle Support
● VGA, BNC and HDMI outputs
● 8x alarm input
● 1x alarm output 1
● The record to 2 hard drives up to 4TB (not included)
● eSATA port for external disk drive
● Estimated space for recording per day: 35 GB of the highest quality, 17 GB to 8 GB of middle and low quality

Technical specifications:

Brand: Xvision
Model Number: XR960D8-1TB
Video Compression: H.264
Video system: NTSC / PAL
Video input/output: 8 CH input, 1 BNC, 1 VGA, 1 HDMI
Spot output: No
Audio input/output: 8 CH input, 1 CH output (RCA)
Display resolution: PAL: 960x576 @ 25fps, NTSC: 960x480 @ 30fps
Display features: Single, Quad, SEQ, 6/8/9 split
Recording Resolution: PAL: D1 mode: 360x288 (CIF), 720x288 (HD1), 720x576 (D1), 960H mode: 480x288 (WCIF), 960x288 (WHD1), 960x576 (WD1) NTSC: D1 mode: 360x240 (CIF), 720x240 (HD1), 720x480 (D1), 960H mode: 480x240 (WCIF), 960x240 (WHD1), 960x480 (WD1)
Recording Speed: NTSC: 25 fps, NTSC: 30 frames per second
Recording Mode: Continuous / manual / motion detection
Playback channels: 1/8 Ch
Playback speed: PAL: 25fps, NTSC: 30fps
DVD - RW: Yes
Sensor & Alarm I / O: Yes
IR Extender Port: No
Network: LAN, DHCP, Dynamic IP & DDNS
HDD Interface: SATA 2 HDD up to 4 TB in total up to 8 TB, E-Sata port for backup
Multiplex operation: live display, record, playback, backup and network
USB: 2 x USB (for mouse and backup / upgrade)
PTZ Control: Built-in RS485, support Pelco - P and Pelco - D
Mobile CMS XR960 - Android and iOS
CMS Software 64 CH DVR 256 pieces, no limit for user
Web browser: Internet Explorer, Safari, Chrome, Firefox
VGA: 1024x768, 1280x1024, 1366x768, 1440x900, 720P, 1080P
HDMI: 1024x768, 1280x1024, 1366x768, 1440x900, 720P, 1080P
Power supply: 12V DC 6000 mA
Fan: Yes
On/Off Switch: Yes
Remote Control: Yes
Rack Mount Size in (U): 1.5 U
Dimensions (WxHxD): 440x70x418mm
