16 channel HD DVR 960H for cameras

SKU: 41-023 I have a question
Manufacturer X Vision
Products availability pre-order
Delivery time 1 - 3 weeks.
Yes! We Ship To US
Price excl. VAT U$ 539.91
Price incl. VAT U$ 647.90
- +

Product description 16 channel HD DVR 960H for cameras

Professional 16 Channel HD DVR Recorder for 960H is the latest professional camera DVR from Xvision with advanced features that offers high resolution 960H and records in real time. It is designed to offer something more than just the standard 960H DVR, supports PTZ cameras through RS - 485, as well as flexible recording modes, including the triggering of the alarm and motion detection.

For easy operation and setup the DVR is equipped with On Screen Display (GUI) and can be controlled via the front panel, remote control or mouse (both are supplied as standard). Besides those it offers VGA, BNC and HDMI output up to 1080p.


16 video inputs and 16 audio inputs (PAL/NTSC compatible)
Supports the following recording resolutions: WCIF, WHD1, WD1 all in 960H and CIF, HD1, D1.
Fully compatible with standard and 960H cameras
Enhanced Xvision H264 compression for longer recording time
Flexible recording modes: continuous, scheduled, alarm or motion detection
Accepts 2 hard drives up to 8 TB, 4 TB per disk
It uses the most modern technology of recordin, resolution 960H
Remote network access from a smartphone, tablet, PC and Mac
Intelligent motion detection starts recording only at movement and starts instantly sending email alerts including images
Simple operation using a USB mouse, remote control, or network
16 x alarm inputs, 2 alarm output
3G/4G Internet USB Dongle Support
Estimated space for recording per day: 35 GB of the highest quality, 17 GB to 8 GB of middle and low quality
DVR for 16 cameras

Technical specifications:

Brand: Xvision
Model number: XR960D16
Video Compression: H.264
Video system: NTSC / PAL
Video input/output: 16 CH Input, 1 BNC, 1 VGA, 1 HDMI
Spot output: No
Audio input/output: Input 16 CH, CH 1 output (RCA)
Display resolution: PAL: 960x576 @ 25fps, NTSC: 960x480 @ 30fps
Display features: Single, Quad, SEQ, 6/8/9/10/13/16 split
Recording Resolution: PAL: D1 mode: 360x288 (CIF), 720x288 (HD1), 720x576 (D1), 960H mode: 480x288 (WCIF), 960x288 (WHD1), 960x576 (WD1) NTSC: D1 mode: 360x240 (CIF), 720x240 (HD1), 720x480 (D1), 960H mode: 480x240 (WCIF), 960x240 (WHD1), 960x480 (WD1)
Recording Speed: NTSC: 25 fps, NTSC: 30 frames per second
Recording Mode: Continuous / manual / motion detection
Playback channels: 1/16 Ch
Playback speed: PAL: 25fps, NTSC: 30fps
DVD - RW: Yes
Sensor & Alarm I / O: Yes
IR Extender Port: No
Network: LAN, DHCP, Dynamic IP & DDNS
HDD Interface: SATA 2 HDD, up to 4TB one, a total of 8 TB, 1x E-SATA port for backup
Multiplex operation: live display, record, playback, backup and network
USB: 2 x USB (for mouse and backup / upgrade)
PTZ Control: Built-in RS485, support Pelco - P and Pelco - D
Mobile CMS XR960 - Android and iOS
CMS Software 64 CH DVR 256 pieces, no limit for user
Web browser: Internet Explorer, Safari, Chrome, Firefox
VGA: 1024x768, 1280x1024, 1366x768, 1440x900, 720P, 1080P
HDMI: 1024x768, 1280x1024, 1366x768, 1440x900, 720P, 1080P
Power supply: 12V DC 6000 mA
Fan: Yes
On/Off Switch: Yes
Remote Control: Yes
Rack Mount Size in (U): 1.5 U
Dimensions (WxHxD): 440x70x418mm
